Lens angle:horizontal: 80 ° diagonal:110 ° vertical: 65°
IP68 Waterproof
DC power: 12V
Working temperature: -30ºC ~ +70ºC
2.9 inch 1.0 mega pixel CMOS image sensor
Support starlight environment, clear color monitoring under weak light
Support high definition video, control signal coaxial transmission, high definition and standard switch output
Support 2D noise reduction and superior low illumination performance
3Rtablet supplies the best auto side view cameras featuring 720P, IP68K waterproof, etc. With the great R&D support, we also offer ODM & OEM services; please kindly contact for details.
Specification
|
Model Spec |
AHD - 720S |
|
HD Waterproof Camera |
|
|
Details |
|
|
Sensor Type |
1/2.9 GC2053 CMOS |
|
System |
PAL / NTSC |
|
Effective Pixel |
1280 (H) x720 (V) |
|
Illumination |
0.01 LUX / F1.2 |
|
Lens |
2.8mm |
|
Shutter |
1/50(1/60) sec. To 1/100000sec.（AUTO） |
|
D/N |
Full color without light |
|
Signal to Noise Ratio |
> 48dB |
|
Synchronously |
Internal |
|
FPS |
50Hz:25fps(1280*720) 60Hz:30fps(1280*720) |
|
IP Rating |
IP68 |
|
Video Output |
HD video output 1.0vp - p75 Ω |
|
Angle |
Horizontal:80 ° C diagonal: 110 ° C vertical: 65° C |
|
Balance Noise Reduction |
Support 2D noise reduction |
|
Backlight Compensation |
Auto |
|
Power |
DC12V±10% ; 250MA±10% |
|
Operation Environment |
-30℃~70℃ RH95% MAX |
|
Power Cord |
0.6M |
|
Connector |
4-pin connector (aviation head) |
|
Weight |
150g |
