720P high definition
Lens angle:horizontal: 80 ° diagonal: 120 ° vertical: 65°
IP65 Waterproof
DC power: 12V
Working temperature: -30ºC ~ +70ºC
Use 1 million progressive scan CMOS, capture moving images
Coaxial HD output，Excellent performance, clear and bright picture
Lux: 0.01Lux@(F1.2,AGC ON), 0LUX with IR
Adaptive Digital Noise Reduction, 3D-DNR 3Rtablet supplies the best bus dome cameras featuring 720P high resolution, IP65 waterproof, night vision, etc. With the great R&D support, we also offer ODM & OEM services; please kindly contact for details.
Lens angle:horizontal: 80 ° diagonal: 120 ° vertical: 65°
IP65 Waterproof
DC power: 12V
Working temperature: -30ºC ~ +70ºC
Use 1 million progressive scan CMOS, capture moving images
Coaxial HD output，Excellent performance, clear and bright picture
Lux: 0.01Lux@(F1.2,AGC ON), 0LUX with IR
Adaptive Digital Noise Reduction, 3D-DNR 3Rtablet supplies the best bus dome cameras featuring 720P high resolution, IP65 waterproof, night vision, etc. With the great R&D support, we also offer ODM & OEM services; please kindly contact for details.
0102030405
Specification
|
Model |
AHD - 720D |
|
Spec |
720P-960P HD Camera |
|
Details |
|
|
Sensor |
1/2.7 ”1064 |
|
System |
PAL/NTSC |
|
Effective Pixel |
1280(H)x960(V), 1280(H)x720(V) |
|
Illumination |
0.01Lux@(F1.2,AGC ON)，0LUX with IR |
|
Lens |
2.8MM,3.6MM (Optional) |
|
Shutter |
Auto |
|
D/N |
Color |
|
Synchronously |
Internal |
|
FPS |
720P@25fps / 720P@30fps |
|
Audio |
Custom made |
|
IP |
IP65 |
|
Video Output |
AHD |
|
Control(Customized) |
|
|
Exposure |
Brightness / Exposure mode / Gain |
|
D/N |
Color/B/W |
|
BW |
ATW/MWB |
|
Video Setting |
Contrast/Sharpness/Color Gain/DNR/Format/DWDR |
|
Language |
CHN1/ESPANOL/CHN2/ITALIANO/ENGLISH |
|
Interface Method Type |
Aviation connector |
|
General |
|
|
Operation Temperature |
-30°C to 70°C |
|
Working Humidity |
Relative humidity less than 90 % |
|
Power |
DC:12V |
|
Size |
Length*width*height(69.1mm*69.1mm*54.7mm) |
